Professional Vertical Filter Co2 Laser Smoke Evacuator Machine
  • Professional Vertical Filter Co2 Laser Smoke Evacuator Machine
  • Professional Vertical Filter Co2 Laser Smoke Evacuator Machine
  • Professional Vertical Filter Co2 Laser Smoke Evacuator Machine

Professional Vertical Filter Co2 Laser Smoke Evacuator Machine

Place of Origin CHINA
Brand Name Astiland
Certification CE, ISO13485
Model Number optima-e
Product Details
Model Number:
Optima-e
Q-Switch:
No
Laser Type:
CO2 Laser
Style:
Stationary
Type:
Laser
Application:
For Commercial
After-sales Service Provided:
Online Support, Video Technical Support
Warranty:
1 Year
Name:
Surgical Smoke Evacuation Co2 Air Filter For Laser Machine
Function:
Smoke Evacuator
Filter:
3 Layer Filter
Noise:
<60db
Control:
Button Control
Voltage:
220-230V
Hose Diameter:
40mm Diameter
Filtration Coefficient:
> 99.999%,0.3μm
Activity Radius Of Suction Nuzzle:
280mm Diameter
Feature:
Smoke Evacuator
High Light:

Dia40mm Smoke Evacuator Machine

,

2m3/min Smoke Evacuator Machine

,

Dia40mm medical smoke evacuator

Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
Selling Units: Single item Single package size: 35X38X85 cm Single gross weight: 25.000 kg Package Type: medical co2 air filter suction smoke evacuator system for laser package: carton box
Delivery Time
7-10 work days
Payment Terms
T/T, Western Union, MoneyGram,Credit card,Paypal
Supply Ability
100 sets per month
Product Description

filter smoke evacuation air evacuator machine co2 laser


Performance description
When carrying out the operation by high-frequency electric knife, CO2 Laser Surgical System, Nd:YAG laser to cut, burn, vaporize, and solidify pathologically changed tissue, will produce many smoke, odor, and particulates. such as steam, CO2, CO, HN3, HCN, H2S, viruses, and other harmful, toxic, awful, smelly oil, fog and smoke, etc.
This Smoke evacuator is designed to effectively absorb and filter surgical smoke, odor, particulates, and other potentially hazardous vapor from surgery/operation. It can purify the air, reduce harmful smoke and ensure the safety of medical workers and patients.


Function and characteristic
1. Low noise
2. Exhaust gas can be absorbed and filtered by multilayer
3. High-speed fan can complete the movement of gas
4. Activity radius of the suction nozzle is wide
5. Security, trustiness, availability.


The composition of the smoke plume produced during laser surgery may cause the operating room team at risk. A smoke Evacuator can be used to effectively Eliminate Toxic Surgical Smoke generated during laser surgery.


Product Principle
Our smoke evacuators are designed to effectively capture and filter surgical smoke to remove odor, particulates, and other potentially hazardous by-products of electro-surgery procedures.


System Features

· Mini-size stationary design with universal wheel allowing for easy movement and minimizing shipping cost.

· High suction, high flow rate centrifugal pump adopted, excellent particle capture
· User-friendly panel with LED indicator, easy to set up and operate
· Long life 1-3 years filter, simple filter changes
· Filter can capture particulates and micro-organisms down to 0.012um and an efficiency of 99.99995%



Technical parameters



Power requirements 220±22VAC,50±1Hz
7 control mode press button switch
Blowing rate 0—3.2m3/min
flow rate regulation potentiometers(non-hierarchical timing) filter mode activated carbon filters, ULPA filters, etc. have four-story.
Hose diameter Φ40mm
Maximum diameter of suction nuzzle Φ58mm
Activity radius of suction nuzzle Φ280mm
Noise <60dB
Filtration coefficient > 99.999%,0.3μm
Filter good quality with 3-layer filtering
Packing size 35cm×38cm×85cm
Gross Weight 23kg
Net Weight 13.5kg
